Introducing Our 16x17 Horizontal Bend LED Neon Flex – 24V | RGBW | Architectural Range

The 16x17 Horizontal Bend RGBW LED Neon Flex delivers full-spectrum colour-changing output plus dedicated white temperatures—perfect for high-end architectural lighting where versatility and consistency are key. Whether accenting exteriors, facades, or dynamic installations, this RGBW flex offers exceptional colour control with robust performance.

Featuring 5050 RGBW LEDs with a density of 84 LEDs per metre, the unit delivers up to 560 lumens per metre and is available in RGB+5000K, RGB+4000K, and RGB+3000K configurations. Built into a flexible silicone housing with an IP68-rated injection-moulded connector, the unit withstands moisture, salt water, solvents, and UV exposure with ease.

The horizontal bend design, compact profile, and 83.3mm cut points provide seamless installation along architectural curves or straight runs. An ideal solution for dynamic lighting schemes requiring both saturated colour and high-quality white light output.

Key Features
Horizontal bend configuration
IP68-rated silicone injection-moulded connector
Dimensions: 16mm x 17mm
RGBW options: RGB+5000K, RGB+4000K, RGB+3000K
Lumen output up to 560lm/m
CRI >80
SDCM <3 for colour consistency
Operating temperature: -40°C to +45°C
Supplied by the metre with 83.3mm cut points
UV, flame, salt water, and solvent-resistant
5-year warranty
Dimmable

Specifications
Voltage: 24V DC
Power Consumption: 15W/m
Length: 16.4 ft (5 m)
LED Density: 84 LEDs per metre
Beam Angle: 110°
CRI: >80
Bend Direction: Horizontal
Min. Bend Diameter: 300mm
Max. Run Length: 8m (single-end) / 16m (double-end)
IP Rating: IP68
IK Rating: IK10
Material: Silicone
Operating Temperature: -40°C to +45°C
Warranty: 5 Years

Installation & Bespoke Options
Supplied by the metre with 83.3mm cut increments, this Neon Flex allows for bespoke cable direction and tailored lengths. Compatible mounting accessories are recommended for optimal installation.
