Introducing Our 16x17 Vertical Bend LED Neon Flex – 24V | CCT Adjustable | Architectural Range

The 16x17 Vertical Bend CCT Adjustable LED Neon Flex offers precise white temperature control, ranging from a warm 2200K to a crisp 5700K, making it ideal for dynamic architectural lighting applications. Designed for projects requiring vertical flexibility, this solution combines robust engineering with versatile colour control.

Utilising high-density 3015 LED chips and a total of 144 LEDs per metre, this flex provides smooth CCT transitions and consistent light output of up to 490 lumens per metre. It is constructed with a UV-resistant silicone housing that features anti-static and self-cleaning properties, helping maintain optical clarity and extending performance in challenging environments.

With a vertical bend direction and a compact 16mm x 17mm profile, the unit is optimised for concealed or curved architectural surfaces. Operating in environments from -40°C to +55°C, it’s built to endure outdoor exposure, including UV, salt water, solvents, and flame.

Supplied by the metre with 83.3mm cut points and equipped with an IP68-rated silicone injection-moulded connector, this lighting system is fully customisable and engineered for demanding installation environments.

Key Features
Vertical bend configuration
IP68-rated silicone injection-moulded connector
Dimensions: 16mm x 17mm
Adjustable white CCT range: 2200K to 5700K
Lumen output up to 490lm/m
CRI >80
SDCM <3 for consistent white output
Operating temperature: -40°C to +55°C
Supplied by the metre with 83.3mm cut points
UV, flame, salt water, and solvent-resistant
5-year warranty
Dimmable

Specifications
Voltage: 24V DC
Power Consumption: 12W/m
Length: 16.4 ft (5 m)
LED Density: 144 LEDs per metre
Beam Angle: 110°
CRI: >80
Bend Direction: Vertical
Min. Bend Diameter: 300mm
Max. Run Length: 15m (single-end) / 30m (double-end)
IP Rating: IP68
IK Rating: IK10
Material: Silicone
Operating Temperature: -40°C to +55°C
Warranty: 5 Years

Installation & Bespoke Options
Supplied by the metre with 83.3mm cut increments, this Neon Flex supports tailored cable directions and lengths. Use with compatible mounting accessories for optimal installation.
