Introducing Our 16x17 Horizontal Bend LED Neon Flex – 24V | RGB | Architectural Range

The 16x17 Horizontal Bend RGB LED Neon Flex is a versatile, colour-changing solution for architectural lighting applications requiring horizontal flexibility. Whether used for façade highlights, signage, or feature lighting, this robust and vibrant LED strip delivers smooth RGB transitions in a sleek, outdoor-ready profile.

Equipped with 5050 RGB chips and 84 LEDs per metre, it offers balanced red (620–625nm), green (520–525nm), and blue (465–470nm) output, delivering a total of up to 345 lumens per metre. The product’s construction includes a UV-resistant silicone body and a durable IP68-rated silicone injection-moulded connector for maximum resilience in external environments.

With a bend-friendly 16x17mm form factor and 83.3mm cut points, this flex is engineered for seamless horizontal integration into curved or straight architectural elements.

Key Features
Horizontal bend configuration
IP68-rated silicone injection-moulded connector
Dimensions: 16mm x 17mm
RGB output (620–625nm red, 520–525nm green, 465–470nm blue)
Total lumen output: up to 345lm/m
Beam angle: 110°
SDCM <3 for colour consistency
Operating temperature: -40°C to +55°C
Supplied by the metre with 83.3mm cut points
UV, flame, salt water, and solvent-resistant
5-year warranty
Dimmable

Specifications
Voltage: 24V DC
Power Consumption: 12W/m
Length: 16.4 ft (5 m)
LED Density: 84 LEDs per metre
Beam Angle: 110°
CRI: N/A
Bend Direction: Horizontal
Min. Bend Diameter: 300mm
Max. Run Length: 10m (single-end) / 20m (double-end)
IP Rating: IP68
IK Rating: IK10
Material: Silicone
Operating Temperature: -40°C to +55°C
Warranty: 5 Years

Installation & Bespoke Options
Supplied by the metre with 83.3mm cut increments, this Neon Flex allows for bespoke installation, including custom cable length and direction. Compatible mounting accessories recommended.
