Ideal for a variety of installations, our 12x17 Horizontal Bend LED Neon Flex is constructed with high quality silicone material and used for horizontal applications. Ideal for dynamic designs in architectural features, retail displays, signage, and residential projects. Crafted with durable materials and precision-engineered, it delivers a sleek, high-end finish with consistent non-spotting illumination.

From architectural elements to decorative lighting, this LED neon flex features professional grade components and high quality materials. Designed to meet the demands of lighting designers, electricians, and contractors, it elevates any space with a seamless, professional-grade lighting solution.

Samples available for this product. Get in touch with our sales team via email, live chat or phone to request a sample.

Key Features
With horizontal bend flexibility, this LED neon has a minimum bend diameter of 120mm. It offers uniform, shadow-free illumination across all colours and is available in 10 metre kits. The durable, anti-yellowing material is indoor and outdoor-ready with an IP67 rating. A 120° beam angle delivers smooth light, and pre-soldered tails enable quick setup. Comes with a 3 year warranty as standard.

Specifications
Voltage: 24V DC
Typ. Power: 12.0W/m
LEDs per metre: 84 LEDs
Cut Points: 83.33mm
Beam Angle: 120°
Dimensions: W12mm x H17mm
Lumens per metre: Up to 765lm
Warranty: 3 Years
IP Rating: IP67 (suitable for indoor and outdoor use)

Installation
The IP67-rated LED Neon Flex is designed for both indoor and outdoor applications, featuring a durable rear-entry cable for easy installation. For optimal performance and secure placement, we recommend using mounting tracks.

Product Specification
Warranty (Years):    3
Max. Run Length (m):    5
Body Material:    Silicone
Ingress Protection (IP):    67
Input Current Type (A):    DC
Input Voltage Min. - Max (V):    24-24V
Body Colour:    White
Cut Points (mm):    83.33
LEDs Per Metre (LEDs/m):    84
Product Height (mm):    17
Color:    RGB Colour Changing
Width (mm):    12
Battery Included:    No
Beam Angle (°):    120
Operating Temperature Min. - Max. (°C):    -20℃ to 45℃
Family Name:    Pro Series
Bend Direction:    Horizontal
Cable Both Ends:    Yes
Cable Length (mm):    1000
Total Lumens (Lm):    5200
Lumens Per Metre (Lm/m):    520
Lumens Per Watt (Lm/W):    433
SDCM:    3
